Fabtech K2190 6" Basic Performance Lift W/Performance Rear Shocks 2009-2013 F-150 4WD SuperCrew 5.4

Fabtech K2190 6" Basic Performance Lift W/Performance Rear Shocks 2009-2013 F-150 4WD SuperCrew 5.4

Fabtech's Basic System for the Ford F150 utilizes a spacer with the factory coilover shock and features Fabtech’s signature arched lower control arm crossmembers constructed of 1/4” thick steel, with integrated differential skid plate to provide strength and rigidity to the front frame and suspension. Crossmembers include adjustable eccentric cams for easy front end alignment and ability to hold alignment under offroad conditions. Fabtech’s proprietary steering knuckles are built with the finest American-made ductile iron and will allow use of an 18" or 20” diameter wheel. Also included in these systems are sway bar brackets, impact struts, blocks and a u-bolt kit. Use 35/13.50R20 tires w/ 20x9 wheels w/ 5” Backspace. Fits SuperCrew w/ 5.4L engine only.

• Fits 2009 to 2013 FORD F150 4WD
• Lift Height: 6 inches
• Front Lift: Crossmember & Steering Knuckles
• Rear Lift: Lift Blocks w/ U-bolts
• Includes: Front factory coilover spacers, diff skid plate, alignment eccentric cams, sway bar drop brackets, impact struts and more.
• Shocks: Rear Performance Shocks only (factory front coilover is retained)
• Shock Boots: Not Included
• Color: Black
• Max Tire Size (in): 35/13.50R20
• Max Wheel Size (in): 20x9
• Backspace: 5

Kit# K2114

• Use 325/65R18 tires w/ 18x9 wheels w/ 5” BS w/ minor trimming
• Use 35/13.50R18 tires w/ 18x9 wheels w/ 5" BS w/ minor trimming
• Use 35/13.50R20 tires w/ 20x9 wheels w/ 5” BS w/ minor trimming

Notes

*FOOTNOTES:

14. Cannot use OEM wheel and tire.
47. Fits SuperCrew models only.
123. Will not fit Raptor models.
